Compact, ceiling-mount WiFi 7 AP with 5 spatial streams and extended signal range.
WRL ACCESS POINT/U7-LR UBIQUITI
WRL ACCESS POINT/U7-LR UBIQUITI
178,31 €
Pagrindinės savybės:
| Produkto informacija | FRT1066059 |
| Liko produktų | 20+ |
- Garantija (mėn.) 12
- Prekių pristatymas Apie 4d.d.
- Likutis 20+
Apie produktą
Produkto ypatybės
Garantija
12
Vendor Homepage
https://eu.store.ui.com/eu/en/category/wifi-flagship/products/u7-lr
Category Code
WAP
Unit Box Height
0.51
Unit Box Length
0.485
Unit Box Width
0.0247
Product colour
White
Operating temperature (T-T)
-30 - 50 °C
Shipping Box Depth
48.5 cm
Shipping Box Height
51 cm
Shipping Box Weight
15.3500003815 kg
Shipping Box Width
39.5 cm
Model name
U7 Long-Range
Unit Calculated Volume
0.006106 cubm
Product Net Weight
0.448 kg
Unit Calculated Weight
0.959 kg
CnCode
85176200
Width
175.7 mm
Height
43 mm
Depth
175.7 mm
Summary
Ubiquiti U7 Long-Range. 2.4 GHz, 5 GHz, Maximum data transfer rate: 7300 Mbit/s. Security algorithms: PPSK, TLS. Ethernet LAN data rates: 1000,2500 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 14 W
Model
U7-LR
Ethernet LAN (RJ-45) ports
1
Power consumption (max)
14 W
Operating relative humidity (H-H)
5 - 95 %
Units per Shipping Box
16
Weight
448 g
Security algorithms
PPSK/TLS
Housing material
Aluminium,Polycarbonate (PC)
Quantity per pack
1 pc(s)
Maximum data transfer rate
7300 Mbit/s
LED indicators
Yes
Compliance certificates
CE/Federal Communications Commission (FCC)/Industry Canada (IC)/National Defense Authorization Act (NDAA)
Frequency band
2.4 - 5 GHz
Antenna Type
Internal
Ethernet LAN data rates
1000/2500 Mbit/s
MIMO type
Multi User MIMO
Mounting kit
Yes
Networking standards
IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11be/IEEE 802.11k/IEEE 802.11n/IEEE 802.11r/IEEE 802.11v
Antenna gain level (max)
6 dBi
Placement
Ceiling,Wall
Power over Ethernet (PoE)
Yes
MIMO
Yes
5 GHz
Yes
6 GHz
No
VLAN support
Yes
Daugiafunkcinio įrankio tipas
12
2.4 GHz
Yes
Number of users
300 user(s)
Maximum data transfer rate (2.4 GHz)
688 Mbit/s
Maximum data transfer rate (5 GHz)
4300 Mbit/s
DC voltage range
42.5 - 57 V
Reset button
Yes
Band steering
Yes
Coverage area
160 m²
Fast roaming
Yes
Fit AP mode features
Hotspot 2.0
Maximum Tx power (2.4 GHz)
26 dBmW
Maximum Tx power (5 GHz)
27 dBmW
Rate limiting
Yes
Spatial streams
5
Wireless meshing
Yes
Remote Authentication Dial-In User Service (RADIUS)
Yes
Access point management
Wi-Fi schedule
