MikroTik | RBcAPGi-5acD2nD | cAP ac | 802.11ac | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 2 | MU-MiMO Yes | Antenna type Internal | 12 month(s)

MikroTik | RBcAPGi-5acD2nD | cAP ac | 802.11ac | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 2 | MU-MiMO Yes | Antenna type Internal | 12 month(s)

72,72 €
Pagrindinės savybės:
Produkto informacija FRT936119
Liko produktų 10

  • Garantija (mėn.) 12
  • Prekių pristatymas Apie 4d.d.
  • Likutis 10

Apie produktą

The cAP ac is a very capable and powerful wireless access point that looks beautiful on both walls and ceilings. The concurrent dual band wireless radio supports dual chain 2 GHz 802.11b/g/n and 5 GHz in a/n/ас standards, and will provide coverage in 360 degrees around it.

Even though the radio supports repeater mode, the two Ethernet ports give you the ability to extend your network with cables, even if PoE power is required, since the cAP ac supports 802.3af/at PoE input on the first port, and passive PoE output on the second port. Device supports IPsec hardware acceleration too.

The cAP ac is a feature packed device with a sleek enclosure, that can become inconspicuous with
the push of a button - the customizable mode button in the device center will turn off all lights and
sounds at it’s default configuration, but can be reconfigured to launch any RouterOS script.

Produkto ypatybės

Garantija
12
Vendor Homepage
https://mikrotik.com/product/cap_ac#fndtn-specifications
mikrotik.com/product/cap_ac
Category Code
WAP
Unit Box Height
0.265
Unit Box Length
0.06
Unit Box Width
0.18
Operating system installed
RouterOS
Product colour
White
Operating temperature (T-T)
-40 - 50 °C
Shipping Box Depth
26.7 cm
Shipping Box Height
18 cm
Shipping Box Weight
0.68 kg
Shipping Box Width
5.8 cm
Model name
cAP ac // RBcAPGi-5acD2nD
Unit Calculated Volume
0 cubm
0.002787 cubm
0.003386 cubm
Product Net Weight
0 kg
0.2 kg
Unit Calculated Weight
0.68 kg
0.718 kg
1 kg
CnCode
85176200
Width
136 mm
Height
136 mm
Depth
30 mm
Summary
Mikrotik cAP ac. 2.4 GHz, 5 GHz, Maximum data transfer rate: 867 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 13 W
Unit Brutto Volume
0.002787 cubm
Shipping box quantity
1
Unit Net Weight
0.2 kg
Unit Gross Weight
0.68 kg
Full Description Line
cAP ac // RBcAPGi-5acD2nD|Type Wireless Access Point|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|IEEE 802.11ac|Dimensions 185x31mm
Ethernet LAN (RJ-45) ports
2
Power consumption (max)
13 W
Internal memory
128 MB
Units per Shipping Box
1
20
Dimensions
185x31mm
Harmonized System (HS) code
85176990
Maximum data transfer rate
867 Mbit/s
LED indicators
Yes
Certification
CE, FCC, IC, EAC, ROHS
Frequency band
2.412 - 2.484, 5.15 - 5.875 GHz
AC adapter included
Yes
Output voltage
57 V
Internal
No
IEEE 802.11n
Yes
Processor frequency
716 MHz
Processor model
IPQ4018
Antenna Type
Internal
Ethernet LAN data rates
10/100/1000 Mbit/s
Mounting kit
Yes
Network Device Type
Wireless Access Point
Networking standards
IEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3af/IEEE 802.3at
IEEE 802.11b
Yes
IEEE 802.11g
Yes
IEEE 802.11ac
Yes
Antenna gain level (max)
2.5 dBi
Flash memory
16 MB
Placement
Ceiling,Wall
Power over Ethernet (PoE)
Yes
5 GHz
Yes
Built-in processor
Yes
Daugiafunkcinio įrankio tipas
12
2.4 GHz
Yes
Receiver sensitivity
2.4GHz: 1MBit/s: -100 @ 26dBm Tx 11MBit/s: -94 @ 26dBm Tx 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -78 @ 23dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -73 @ 22dBm Tx 5GHz: 6MBit/s: -96 @ 26dBm Tx 54MBit/s: -80 @ 21dBm Tx MCS0: -96 @ 26dBm Tx MCS7: -75 @ 20dBm Tx MCS9: -7
Maximum data transfer rate (2.4 GHz)
300 Mbit/s
Maximum data transfer rate (5 GHz)
867 Mbit/s
DC voltage range
17 - 57 V
Power over Ethernet (PoE) type supported
Active PoE/Passive PoE
Antenna features
Integrated antenna
PoE adapter included
Yes
Antennas quantity
4
